Availability: | |
---|---|
With RS485 interface, it can control SVG and smart capacitors at the same time;
It can monitor the switching status of SVG and capacitors;
High detection accuracy, electrical parameter accuracy is not more than 1%;
Complete functions, with overvoltage and undervoltage protection, harmonic voltage protection and other functions;
The capacitor control scheme supports three-phase common compensation, sub-compensation, hybrid compensation, etc., which can be selected through parameter settings;
Supports cyclic switching for equal-capacity capacitors, and preferential switching for unequal-capacity capacitors;
It has two working modes of automatic/manual compensation;
Strong redundancy, when the SVG fails, the switching of the capacitor can still be controlled.
12 groups of dry contact control signals;
2 groups of temperature detection and protection;
3 groups of switch signal input;
4 groups of switch signal output;
1 channel RS485 communication.
With RS485 interface, it can control SVG and smart capacitors at the same time;
It can monitor the switching status of SVG and capacitors;
High detection accuracy, electrical parameter accuracy is not more than 1%;
Complete functions, with overvoltage and undervoltage protection, harmonic voltage protection and other functions;
The capacitor control scheme supports three-phase common compensation, sub-compensation, hybrid compensation, etc., which can be selected through parameter settings;
Supports cyclic switching for equal-capacity capacitors, and preferential switching for unequal-capacity capacitors;
It has two working modes of automatic/manual compensation;
Strong redundancy, when the SVG fails, the switching of the capacitor can still be controlled.
12 groups of dry contact control signals;
2 groups of temperature detection and protection;
3 groups of switch signal input;
4 groups of switch signal output;
1 channel RS485 communication.
Performance
| target power factor | -1~1 |
switching mode | Cyclic switching/coding switching | |
Switching method | Manual / Auto | |
Compensation method | Sub-compensation / Co-compensation / Hybrid compensation | |
CT | 0~4000 | |
input threshold | 0~200kvar | |
cutout threshold | 0~ 200kvar | |
input delay 1 | 1s~60s | |
Cut Delay 1 | 1s~60s | |
input delay 2 | 0.1s~60s | |
Cut Delay 2 | 0.1s~60s | |
Overvoltage limit | 220V~265V | |
Pressure loss limit | 175V~ 220V | |
voltage hysteresis | 5~12V | |
Voltage Harmonic Limits | 3%~ 20% | |
Current Harmonic Limits | 5%~ 50% | |
Measuring voltage | 176V~ 264V | |
Measuring current | 0~4000A | |
Measuring frequency | 45~65HZ | |
Terminal interface | Power supply terminal | Working power interface, AC 220V 50Hz |
Current sampling terminal | Sampling current signal interface | |
Voltage sampling terminal | Sampling voltage interface | |
Rs485 | remove Rs485 interface, connect APF/SVG | |
Rj45 | Rj45 interface, connected with smart capacitor | |
OUT1~2 | Switch signal output | |
IN1~2 | Switch signal input | |
NTC | temperature sensor interface | |
Operation environment | Altitude | ≤2500m |
Operating temperature | - 20°C~60°C | |
storage temperature | -25°C~70°C | |
Relative humidity | 90% No condensation | |
Working power | AC 220V士20% | |
Ct secondary current | 5A | |
Ct range | 150A~4000A |
Performance | Output type | Relay output, normally open contact, dry contact |
Contact power | 250VAC 5A | |
Communication type | MODBUS communication | |
Terminal interface | Power supply terminal | Working power interface,DC 24V |
Rs485 | RS485 interface, connect to APF/SVG | |
Rj45 | Rj45 interface, connect smart capacitor | |
OUT1~12 | Dry contact signal output | |
IN1~3 | switch signal input | |
NTC | emperature sensor interface | |
Operation environment | Altitude | ≤2500m |
Operating temperature | -20°C~60°C | |
Storage temperature | -25°C ~70°C | |
Relative humidity | 90% No condensation | |
Working power | DC 24V |
Performance
| target power factor | -1~1 |
switching mode | Cyclic switching/coding switching | |
Switching method | Manual / Auto | |
Compensation method | Sub-compensation / Co-compensation / Hybrid compensation | |
CT | 0~4000 | |
input threshold | 0~200kvar | |
cutout threshold | 0~ 200kvar | |
input delay 1 | 1s~60s | |
Cut Delay 1 | 1s~60s | |
input delay 2 | 0.1s~60s | |
Cut Delay 2 | 0.1s~60s | |
Overvoltage limit | 220V~265V | |
Pressure loss limit | 175V~ 220V | |
voltage hysteresis | 5~12V | |
Voltage Harmonic Limits | 3%~ 20% | |
Current Harmonic Limits | 5%~ 50% | |
Measuring voltage | 176V~ 264V | |
Measuring current | 0~4000A | |
Measuring frequency | 45~65HZ | |
Terminal interface | Power supply terminal | Working power interface, AC 220V 50Hz |
Current sampling terminal | Sampling current signal interface | |
Voltage sampling terminal | Sampling voltage interface | |
Rs485 | remove Rs485 interface, connect APF/SVG | |
Rj45 | Rj45 interface, connected with smart capacitor | |
OUT1~2 | Switch signal output | |
IN1~2 | Switch signal input | |
NTC | temperature sensor interface | |
Operation environment | Altitude | ≤2500m |
Operating temperature | - 20°C~60°C | |
storage temperature | -25°C~70°C | |
Relative humidity | 90% No condensation | |
Working power | AC 220V士20% | |
Ct secondary current | 5A | |
Ct range | 150A~4000A |
Performance | Output type | Relay output, normally open contact, dry contact |
Contact power | 250VAC 5A | |
Communication type | MODBUS communication | |
Terminal interface | Power supply terminal | Working power interface,DC 24V |
Rs485 | RS485 interface, connect to APF/SVG | |
Rj45 | Rj45 interface, connect smart capacitor | |
OUT1~12 | Dry contact signal output | |
IN1~3 | switch signal input | |
NTC | emperature sensor interface | |
Operation environment | Altitude | ≤2500m |
Operating temperature | -20°C~60°C | |
Storage temperature | -25°C ~70°C | |
Relative humidity | 90% No condensation | |
Working power | DC 24V |
