PRODUCT CLASSIFICATION

CMC-MX series motor soft starters are suitable for soft start and soft stop of standard squirrel cage asynchronous motors.

● Start and stop the motor smoothly to avoid electrical shock;

● With built-in bypass contactor, save space, easy to install;

● Wide range of current and voltage settings, torque control, adaptable to various loads;

● Equipped with multiple protection features;

● Support Modbus-RTU communication

Applicable motor: Squirrel cage AC asynchronous(induction) motor

Mains voltage: AC 380V

Power range: 7.5 ~ 280 kW

CMV series soft-start device is designed to efficiently start, control, protect, and soft-stop high-voltage squirrel-cage asynchronous and synchronous motors.

It’s a new type of intelligent equipment with high performance, multi-function, and high safety.

✔ 32-bit ARM core microprocessor, optical fiber drive, multiple dynamic and static voltage equalization protection;

✔ Reduce the starting impulse current of the motor and reduce the impact on the power grid and the motor itself;

✔ Reduce the impact on mechanical equipment, prolong its service life, and reduce failures and downtime.

Mains voltage: 3kV ~ 10kV

Frequency: 50/60Hz±2Hz

Communication: Modbus RTU/TCP, RS485

XFC500 general-purpose series VFD utilizes a high-performance DSP control platform as its core, enabling precise control and regulation of asynchronous motors through an excellent speed sensorless vector control algorithm, especially for fan and water pump load applications.

Input voltage: 3phase 380V ~ 480V, 50/60Hz

Output voltage: consistent with the input voltage

Power range: 1.5kW ~ 450kW

√ Models with a power rating of 132kW and higher are equipped with built-in DC reactors.

√ Flexible application function expansions, mainly including IO expansion card and PLC expansion card.

√ The expansion interface allows for the connection of various communication expansion cards such as CANopen, Profibus, EtherCAT, and others.

√ Detachable LED operation keyboard.

√ Common DC bus and DC power supplies are both supported.

XICHI’s MAXWELL H series Variable Frequency Drives are versatile devices used to optimize motor performance, enhance energy efficiency, and provide fine-tuned control in a wide range of applications.

Input voltage ranges: 3.3kV ~ 11kV

Power range: 185kW ~ 10000kW.

Applied for a wide range of industrial applications:

For general loads, such as pumps, fans, compressors, conveyor belts;

For special loads, such as compactors, crushers, extruders, mixers, mills, kilns, etc.
